Industrial Lab/Bench Ovens

Bench Ovens

Although smaller than most of our industrial ovens, JPW’s lab/bench ovens are mighty, producing high heat for drying, curing, testing, baking, finishing, aging and other process needs. They are usually used in the industrial setting when small batches of product are needed, or the size of the workspace is limited. These ovens are often positioned on a table or bench but can also be floor-mounted depending on the setting. Lab/bench ovens often use wheeled racks, carts, or trays to simplify the heating process. There are a variety of industries that regularly use the lab/bench ovens including, aerospace, medical, solar, metal-finishing, pharmaceutical, and education.



Air Flow Patterns

Upward PatternLeftward PatternCrisscross PatternCenter-Up Pattern

Standard Features

  • UL-approved 508A
  • Designed to NFPA 86
  • TEFC motors (totally enclosed fan cooled)- for harsh environments and long life
  • Controls – all digital, microprocessor, thermocouple input temperature controller
  • Circuit breakers on motor in lieu of fusing – easy troubleshooting, no fuses required for motors
  • Oven on switch – Illuminated
  • Heat on switch – Illuminated
  • Batch Timer – shuts heat off at the end of a timed cycle (on models with single set point controllers only)
  • SSR or SCR power controllers
  • High volume recirculation blowers or fans
  • Pressure differential switches – in the event of the loss of air the heating system will shut down
  • 8lb density mineral wool board insulation
  • Painted exterior
  • Incoloy sheathed heating elements
  • Pressure relief latches
[Expand][Close]

Optional Features

  • Forced exhaust packages
  • Gas-fired – natural or propane
  • Programmable controllers
  • Recorders
  • Solvent rated
  • Door switch
  • Shelves
  • Carts
  • Proportional dampers
  • Inert gas purge & process
  • Viewing window
  • Interior light
  • Stainless interior
  • Stainless sealed interior
  • Wall ports
  • Cascade controlling (two loops, typically one air and one product)
  • Class 1, Div 2
  • 24/7 timer
  • Audible/visual alarm indicators
  • Vertical lift door
  • Custom designs
[Expand][Close]
  • In-stock and ready for immediate delivery oven

    BT3.56

    • Internal Size 19W x 18D x 18H
    • External Size 35W x 32D x 39H
    • Volume 3.56 CUFT
    • Metal Stainless Steel
    • Fan400 CFM
    • Airflow Horizontal
    • Temperature 500°F

  • In-stock and ready for immediate delivery oven

    ST222

    • Internal Size 24W x 24D x 24H
    • External Size 57W x 36D x 51H
    • Volume 8 CUFT
    • Metal Stainless Steel
    • Fan400 CFM
    • Airflow Horizontal
    • Temperature 500°F
